| POWER: | BRUSHED |
| NO.: | 94512 |
| NAME: | VPRTEX |
| DRIVE: | 4WD |
| LENGTH: | 400mm |
| WIDTH: | 245mm |
| HEIGHT: | 235mm |
| WHEEL BASE: | 280mm |
| GROUND CLEARANCE: | 26mm |
| WHEELS: | 85*32mm(F)85*42mm(R) |
| GEAR RATIO: | 8.33:1 |
| WEIGHT: | 1.7KG |
| SERVO: |
15KG |
| ESC: | 60A |
| MOTOR: | RC550 |
| ENGINE: | |
| FUEL TANK: | |
| BATTERY: | 7.4v 3500mAh |
| CHARGER SPEC: | 11.1/7.4V800mA |
| RADIO/RX: | 4CH/2.4GHz |
| R/C DISTANCE: | >110m |
| SPEED: | >30KM |
| BODY COLOR: | PC 1.0 |
| QTY: | 45.5*28.5*16.5CM |
| QTY: | 4P |
| MEAS: | 47*30*69.5CM |
FEATURES:
1. Ready to run model,The bodyshell uses the PC material and the appearance uses Aerodynamic streamline idea.
2. All the electrical components is splash-proof,And the transmitter uses the FS new 2.4G anti-runaway 4CH G4P standard
version
3. Integrated screw-free chassis design, gears and electronic wiring concealed layout , simple and beauty appearance, easy
to disassemble and anti-dust.
4. All-bearings,front and rear adjustable link,front and rear differential box use metal gears and anti-oil leakage seal design.
5. 5.8mm aluminum central metal driveshaft,steel main gear with anti-slipper buffer and fully sealed dust cover.
6. #1144 high carbon steel front and rear driveshafts,the front driveshaft uses CVD structure design.
7. higher suspension system,bigger size Metal adjustable shock absorber,with the shock spring having anti-falling fender and
adding shock ball-end protection cover.
8. the Aerodynamic Streamline wing equipped with the front narrow wheel and rear wide wheel,make the car easy to speed up
and jump and conquer all-terrain trail.
